feeding unit
-: with independent intellectual property rights the leading egde of the paper feeding system.to adapt
   to warping board.to adapt to hign speed,paper feed stabiliy is good.
-:can be continuous or skip feeding paper
-: leading edge location,frequency conversion air volume control,in order to apply to all kinds of    cardboard size ,high precison feed.
-:double feeding roller.reduce the damage for cardboard strength ,and ensure the life of the rubber   roller
-: adjustable floating paper rubber follers system,improve the feed accu-racy.
-: confetti brush and negative pressure dust removal system to remove cardboard surface dust.

print unit
-:thick steel press plate rolls with grinding and chrome-plated surface and engraved reticulation convenient for pasting(hange )plate.
-:quick plate-hanging device can save the time of pasting.
-:press plate is fixed or removed by step switch electrical control over clockwise and anticlockwise revolving.
-:manual adjustment over dial of press roller clearance.
-:printing phase fixed device,pneumatic braking devices with braking machanism to lock rotation of press plate roll and maintain the fixing
  point of original gears when the printing machinie breaks away.
-:reticulate roll assists paper feed system and pneumatic auto lifting device.
-:international standard high-precision harmoinc phasing device PLC card touch-screnn controlled 360 angle adjustment,auto zero adjustment.
-:manual horizontal adjustment with adjustment distance of +_10mm.

slotting
-:single shaft double cutter slotting.adjustment of boxes height adopts internal gear structure.preventing the cartons from the pollution of lubbricating oil easliy.
-:slotteed cutter with horizontal moving structure,high precision bimetal with guide shaft ,make it is movement flexible and accurate.
-:elastic sheat angle structure,make three ,five layers cardboard corner cut without adjusting ,operation more convenient.
-: special structure of two line pressing keep the board from crushing while it is pressing.
-:phase adjustment adopts planetary gear structure,long service life.
-:with portable punching mold base(optional)

die cutting unit
-:roller adopts button optional force glue pads,easy to tear open and replace.
-:the surface of rubber pad with omdification mechanism,keep the die cutting precise,increase itis service life longer.
-:rubber adjustment adopts planetary gear structure,long service life.
-:equipment with a speed difference compensation mechanism ensure a uniform linear veloctiy and improve the precision die cutting.
